| Brand | Ebeestock |
| Impedance | 50 Ohm |
| Item Dimensions LxWxH | 6.69 x 0.51 x 4.72 inches |
| ItemWeight | |
| ProductDimensions |
Product features
- Active GPS Navigation and 4G LTE Cellular Omni-directional Combined Antenna;
- Feature: Adhesive Magnetic Mounting; Connector: Dual SMA Male Connector; Cable: Dual 3m Cable;
- Package List: 1 x Antenna;(As the Picture Shown)
- Compatible with: Vehicle Car 4G LTE TCU Telematics; 4G LTE GPS Tracker Locator; Vehicle RV Bus Truck Boat Mobile DVR Camera Security Real Time Video Recorder; Bus Truck RV Van Security Alarm System, 4G LTE Industrial Gateway Mobile Router;
- Compatible with: Internet Of Things IOT; Machine-to-Machine M2M; Industrial Vending Machine DTU Gateway Modem Terminal Server; Trail Camera;
Product Description
Specifications:
4G LTE Cellular Antenna Specification:
Frequency Range: 698-960 MHz, 1710-2170 MHz, 2300-2700 MHz
V.S.W.R: <2.0
Polarization: Linear
Gain: 5dBi
Impendance: 50Ω
GPS Antenna Specification:
Center Frequency: L1:1575.42MHz±1.023 MHz
Band Width： >9MHz
Polarization: RHCP
Gain: 2dBic（Zenith）
V.S.W.R: <1.5
Impendance: 50Ω
Axial Ratio: 3dB（max）
LNA Gain: 28±2dB
LNA Noise Figure: <1.5
LNA V.S.W.R: <2.0
LNA Supply Voltage: 2.2~5V DC
LNA Current Consumption: 5~15mA
Mechanical:
Cable: RG174
Cable Length: 3 Meters
Connector: Dual SMA Male Connector
Material: ABS
Mounting Method: Adhesive Magnetic Mounting
Package List: 1 x Antenna (As the Picture Shown)
